Black-i HDMI 1 In 8 Out Splitter – 4K@30Hz
Black-i BI-HD108 HDMI 1 In 8 Out Splitter
The Black-i BI-HD108 HDMI 1 In 8 Out Splitter is a high-performance HDMI distribution solution designed to duplicate one HDMI source across up to eight HDMI displays simultaneously. It is ideal for applications where the same content needs to be displayed on multiple TVs, monitors, projectors, or other HDMI-enabled screens.
4K Ultra HD Support
The Black-i BI-HD108 supports resolutions up to 4K × 2K @ 30Hz, delivering clear and detailed video across compatible displays. With HDMI 1.4 compatibility and bandwidth of up to 10.2Gbps, it provides stable HDMI signal distribution for high-definition applications.
1 HDMI Input to 8 HDMI Outputs
Connect a single HDMI source to the input and distribute the same video signal to eight HDMI displays at the same time. Every connected display shows identical content from the HDMI source.
Important: The Black-i BI-HD108 supports screen duplication/mirroring only. It does not support extended desktop or independent display output.
Wide Device Compatibility
The Black-i BI-HD108 works with a wide range of HDMI devices, including laptops, PCs, set-top boxes, gaming consoles, cameras, media players, Blu-ray players, HDTVs, monitors, and projectors.
Reliable Metal Construction
Designed with a durable metal housing, the Black-i BI-HD108 is built for reliable everyday use in both home and professional environments. Its Plug & Play design requires no additional drivers or software.
Simply connect your HDMI source, connect up to eight HDMI displays, connect the power supply, and start duplicating your content.
Audio Support
The Black-i BI-HD108 supports LPCM, DTS, and Dolby Digital audio formats for compatible HDMI audio transmission, providing a complete audio-visual experience.
Key Features
-
1 HDMI Input to 8 HDMI Outputs
-
Duplicates one HDMI source to eight displays
-
Supports up to 4K × 2K @ 30Hz
-
HDMI 1.4 compatible
-
Up to 10.2Gbps bandwidth
-
Supports 30-bit, 36-bit, and 48-bit colour depth
-
Supports LPCM, DTS, and Dolby Digital
-
Durable metal housing
-
Plug & Play – No Driver Required
-
Compatible with TVs, monitors, projectors, and other HDMI displays
-
Compatible with laptops, PCs, gaming consoles, cameras, media players, and more
-
DC 5V / 2A power supply
-
Suitable for home, commercial, and professional AV setups
-
1-Year Warranty
Technical Specifications
| Specification | Details |
|---|---|
| Model No. | BI-HD108 |
| Brand | Black-i |
| Product Type | HDMI 1 In 8 Out Splitter |
| Function | HDMI Signal Duplication / Distribution |
| Supported Resolution | Up to 4K × 2K @ 30Hz |
| HDMI Version | HDMI 1.4 |
| Input Port | 1 × HDMI |
| Output Ports | 8 × HDMI |
| Bandwidth | Up to 10.2Gbps |
| Colour Depth | 30-bit / 36-bit / 48-bit per pixel |
| Audio Support | LPCM, DTS, Dolby Digital |
| Power Supply | DC 5V / 2A |
| Housing | Metal |
| Installation | Plug & Play |
| Driver Required | No |
| Display Mode | Duplicate / Mirror Only |
| Warranty | 1 Year |
Ideal For
Digital Signage • Retail Displays • Showrooms • Conference Rooms • Classrooms • Training Rooms • Home Entertainment • Corporate Presentations • AV Installations • Multi-Screen Mirroring
Black-i BI-HD108
One HDMI Source. Eight Displays. One Identical View.
The Black-i BI-HD108 provides a simple and reliable way to duplicate one HDMI source across multiple displays, combining 4K Ultra HD support, stable signal distribution, wide compatibility, durable metal construction, and Plug & Play operation.
